TE-VD1108S1-CEPW
TVT IP Intercom Door Station
2MP Pixel, 2.3mm Lens, IR and white LED lights, POE, 2.4G Wi-Fi, Built-in micro SD card slot, Built-in card reader for M1/EM card, up to 8 buttons
- 2MP (1920×1080) real-time H.265 coding
- Auto day-night switch
- Support 3D DNR, HWDR, BLC, HLC, etc.
- Built-in card reader for M1/EM card
- Support door opening by indoor station or by mobile APP or by swiping card
- Support 2.4G Wi-Fi
- Intelligent analytics: video exception detection, person detection, face detection, face capture
- Support noise suppression and echo cancellation
- Customized nametag buttons calling design for easier calls
- Support four button module options: 1/2/4/8 buttons
- Backlight compensation behind the nametag buttons
Standard PoE power supply - IK08 & IP65 higher protection level with aluminum alloy materia
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Image Resolution | 1920×1080 |
| Lens | 2.12mm@F2.0 |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Audio Compression | G711A/U |
| Card Type | Mifare card /Desfire card/FM1208 Card/Gicard /EM Card |
| Card Reading Frequency | 13.56MHz & 125KHz |
| Card Capacity | 15000 |
| Button | Up to 8 buttons, 1, 2, 4 or 8 buttons configurable |
| Network | 100M RJ45 |
| WiFi | Supports 2.4G WiFi function |
| Storage | Built-in micro SD card slot, up to 256GB |
| Ingress Protection | IP65 |
| Power | DC12V/POE |
| Dimensions | 91mm×174mm×32.4mm |
